BPF-A127+

Lumped LC Band Pass Filter, 118 - 137 MHz, 50Ω

Features

• High rejection• Good VSWR, 1.3:1 typ @ passband

• Shielded case•

 Aqueous washable

Applications

• Military communications

• Harmonic rejection

• Transmitters/receivers

Maximum RatingsOperating

Temperature -40oC to 85oC

Storage Temperature -55oC to 100oC

RF Power Input* 0.5W at 25°C
